The production process of double sided PCB
Double-sided or 2 layer PCB is usually made of epoxy glass cloth copper-clad laminates. It is mainly used for communication electronic equipment, advanced instruments, and electronic computers with high-performance requirements.
The production process of two sided PCB can be generally divided into several methods, such as process wire method, hole plugging method, masking method, and pattern plating-etching method.
Advantages of double layer PCB
As one of the professional PCB fabrication companies in China, ZF Electronics will introduce some features of double sided printed circuit boards:
It makes it relatively easy to add conductive paths on the board, which means you will have a PCB that better suits your needs.
As both sides are conductive, a large number of ICs and components can be assembled at any time.
You can add more components as needed as there is an extra layer.
More space and flexible design allow the PCB to suit your requirements.
Dual layer PCB is ideal for demanding applications and advanced electronics.
If necessary, the size of the double-sided PCB can be reduced, because double sides can be used.
This type of printed circuit board for sale may save you money because you may only need one.
Double-sided PCBs can be used in many different applications and electronic products, suitable for a wide range of industries.
The difference between double sided PCB and single sided PCB
Appearance: A single sided circuit board only has one layer, but the double-sided PCB has 2 layers, with a via hole connecting double sided PCB circuit.
Different production processes: The 2 sided PCB has a copper sink process, which is for the two-sided circuit conduction.
Parameters of 2 layer PCB board
Min.Hole Size: 0.3mm
Inner Layer Copper Thickness: 35μm
Outer Layer Copper Thickness: /
Surface Finish: OSP, HASL, HASL LF, Immersion Gold, ENIG
Min. Clearance of Hole to Line: 0.127mm
If you have questions about our double-sided PCB production capacity, double sided PCB price, or the specifications required for your custom project are not listed on this page, please feel free to contact us. We will reply within one workday. Meanwhile, if you want to buy double sided PCB, we are also here to provide quotation support and design support. Welcome to learn about our production process.
