Free DFM Check

Free DFM Check

We provide our customers DFM for free, make sure the product of design, production, surface finished and components are the most appropriate. It will avoid the risks of manufacture greatly, and it will find out the defective products before mass production or prototype and optimizing.



  • DFM checklist

  • Files version and latest updated time

  • Surface Finshed: Lead free/ with Lead

  • Clearly components marking and silkscreen

  • Completed BOM including manufacturer, part number, description and Designator

  • PCB specification: material, thickness, copper, layers, surface finshed, silkscreen colors and special requirements

  • Correct PCB stackup and panelized

  • Provide correct SMT files

  • Completed programmable and testing method

  • Clearly assembly manual with finished product

  • Other special manufacture requirements

  • BOM and PCB pad inspection (some of customers changed the Gerber files and didn’t update BOM in time, that caused sourcing wrong components)

  • Evaluation PCB manufacturing, including but not limited to: sequence of assembly, stencil type, direction before oven and tool production, analysing heat-absorbing pads and surrounding components, moisture sensitive device/thermosensitive device protection, PCBA testing plan and detectable rate, quantity for trial production and report etc.
